Structural, Thermal, and Surface Properties of PVDF/Silica Aerogel Nanocomposite Membranes for Membrane Distillation Application
DOI:
https://doi.org/10.11113/jamst.v29n2.321Keywords:
Sublayer, contact angle, hydrophobicity, thermal conductivity, silica aerogel nanoparticles, membrane distillationAbstract
This study addresses membrane distillation's key challenges - wetting and thermal inefficiency - by developing PVDF/silica aerogel nanocomposite membranes with optimized sublayer properties. We fabricated membranes with systematic variations in PVDF concentration (12-21%) and silica aerogel loading (1-3%), characterizing their structural and surface properties. FTIR analysis confirmed successful nanoparticle incorporation without altering PVDF chemistry. Porosity exhibited concentration-dependent behavior: increasing with silica at 12% PVDF, stable at 18%, and decreasing at 21% due to viscosity effects on phase separation. All nanocomposites showed reduced thermal conductivity, enhancing insulation. While skin layer hydrophobicity remained constant, silica migration significantly increased sublayer contacts angles (peak 130.6° for 18% PVDF/3% silica, 20% improvement over control). The 18% PVDF formulation demonstrated optimal balance, maintaining structural integrity while achieving high porosity (78.3%) and low thermal conductivity (0.048 W/mK). These results highlight two critical findings: (1) PVDF concentration dictates nanoparticle effects on membrane morphology, and (2) strategic silica incorporation simultaneously enhances sublayer hydrophobicity and thermal resistance without compromising mechanical stability. The study provides a design framework for MD membranes, demonstrating how sublayer engineering can mitigate wetting while improving thermal efficiency - crucial advancements for practical MD implementation.
References
Service, R. F. (2004). Nanotechnology grows up. American Association for the Advancement of Science.
Xiang, J., Zhang, L., Li, W., Zhang, H., & Li, J. (2023). Study on low thermal-conductivity of PVDF@SiAG/PET membranes for direct contact membrane distillation application. Membranes, 13(9), 773. https://doi.org/10.3390/membranes13090773.
Gontarek-Castro, E., & Castro-Muñoz, R. (2024). How to make membrane distillation greener: A review of environmentally friendly and sustainable aspects. Green Chemistry. https://doi.org/10.1039/D4GC01136A.
Shirazi, M. M. A., & Kargari, A. (2015). A review on applications of membrane distillation (MD) process for wastewater treatment. Journal of Membrane Science and Research, 1(3), 101–112.
Chen, X., Zhang, Y., Wang, D., Li, J., & He, G. (2018). Tubular hydrophobic ceramic membrane with asymmetric structure for water desalination via vacuum membrane distillation process. Desalination, 443, 212–220.
Ali, A., Ong, Y. K., Chung, T. S., & Lai, S. O. (2019). A comparative analysis of flat sheet and capillary membranes for membrane distillation applications. Desalination, 456, 1–12.
Nthunya, L. N., Derese, S., Mhlanga, S. D., & Mamba, B. B. (2020). f-MWCNTs/AgNPs-coated superhydrophobic PVDF nanofibre membrane for organic, colloidal, and biofouling mitigation in direct contact membrane distillation. Journal of Environmental Chemical Engineering, 8(2), 103654.
Rezaei, M., Hashemifard, S. A., & Abbasi, M. (2022). On performance of polycarbonate/silica aerogel nanoparticle mixed matrix hollow fiber membrane coated with polydimethylsiloxane for membrane distillation. Journal of Applied Polymer Science, 139(31), e52719.
Wang, K. Y., Foo, S. W., & Chung, T.-S. (2009). Mixed matrix PVDF hollow fiber membranes with nanoscale pores for desalination through direct contact membrane distillation. Industrial & Engineering Chemistry Research, 48(9), 4474–4483.
Qtaishat, M., Matsuura, T., Kruczek, B., & Khayet, M. (2008). Heat and mass transfer analysis in direct contact membrane distillation. Desalination, 219(1–3), 272–292.
Gryta, M., Tomaszewska, M., & Karakulski, K. (2006). Wastewater treatment by membrane distillation. Desalination, 198(1–3), 67–73.
Li, Z., Wang, X., Zhang, Y., & Zhang, L. (2014). Effects of thermal efficiency in DCMD and the preparation of membranes with low thermal conductivity. Applied Surface Science, 317, 338–349.
Lee, E.-J., Deka, B. J., & An, A. K. (2019). Reinforced superhydrophobic membrane coated with aerogel-assisted polymeric microspheres for membrane distillation. Journal of Membrane Science, 573, 570–578.
Zhang, L.-Z., & Su, Q.-W. (2018). Performance manipulations of a composite membrane of low thermal conductivity for seawater desalination. Chemical Engineering Science, 192, 61–73.
Deka, B. J., Lee, E.-J., & An, A. K. (2019). Electrospun nanofiber membranes incorporating PDMS-aerogel superhydrophobic coating with enhanced flux and improved antiwettability in membrane distillation. Environmental Science & Technology, 53(9), 4948–4958.
Zhang, H., Zhang, L., Zhang, J., Li, J., & Wang, Y. (2018). SiO₂-PDMS-PVDF hollow fiber membrane with high flux for vacuum membrane distillation. Desalination, 429, 33–43.
Efome, J. E., Rana, D., Matsuura, T., & Lan, C. Q. (2015). Effects of superhydrophobic SiO₂ nanoparticles on the performance of PVDF flat sheet membranes for vacuum membrane distillation. Desalination, 373, 47–57.
Li, K., Zhang, X., Wang, Y., Zhang, L., & Li, J. (2020). A polyvinylidene fluoride (PVDF)–silica aerogel (SiAG) insulating membrane for improvement of thermal efficiency during membrane distillation. Journal of Membrane Science, 597, 117632.
Lovineh, S. G., Asghari, M., & Rajaei, B. (2013). Numerical simulation and theoretical study on simultaneous effects of operating parameters in vacuum membrane distillation. Desalination, 314, 59–66.
Naim, R., & Ismail, A. (2013). Effect of polymer concentration on the structure and performance of PEI hollow fiber membrane contactor for CO₂ stripping. Journal of Hazardous Materials, 250, 354–361.
Khalifa, A., Ahmed, M., & Osman, A. (2017). Experimental and theoretical investigations on water desalination using direct contact membrane distillation. Desalination, 404, 22–34.
Adnan, S., Johnson, D., Hilal, N., & Francis, L. (2012). Commercial PTFE membranes for membrane distillation application: Effect of microstructure and support material. Desalination, 284, 297–308.
Huang, Z., Liu, Z., Li, L., Liu, J., & Zhang, Y. (2021). Dual-layer membranes with a thin film hydrophilic MOF/PVA nanocomposite for enhanced antiwetting property in membrane distillation. Desalination, 518, 115268.
